Inclination Sensor, Digital 2-axis Type

Model: D2NE-HD │ ID: DW

Technical Features:

• Measuring range +/-45° (each axis)
• Analog output 4…20 mA / 0…10 V
• Supply 24 VDC +/-20% / 12 VDC +/-20%
• Resolution better than 0,1°
• Optionally: interface / display / limit value switch
• Protection: IP65
• Sensor operates absolutely without wearing



Application Areas:

• Mounted on objects to detect slope/tilt and prevent overturn (e.g. cranes, ships, ferry ramps)
• High-accuracy digital signal processing with easy adjustment
• Optional interfaces & limit switches expand application range
